The Coretech 845 Dual OA Knee Brace is designed to provide medial and lateral offloading support for individuals managing chronic knee conditions such as osteoarthritis. The dual-hinge system aids in redistributing pressure across the knee joint to enhance stability during extended use.
Straps can be measured and trimmed to accommodate a customized clinical fit. Hinge flexion adjustments can be made using the included keys to suit the prescribed range of motion. Lightweight construction and non-slip padding support consistent brace positioning and breathability during daily clinical wear.
Special Features
Medial and Lateral Offloading Support
Redistributes joint pressure across both sides of the knee to support alignment and joint stability in chronic conditions such as osteoarthritis.
Clinically Adjustable Fit
Straps can be measured and trimmed by medical professionals to ensure a customized clinical fit.
Multiple Size Options
Available in small, medium, large, and extra-large to accommodate a range of patient anatomies.
Customizable Design
Simply adjust the straps by measuring them to the desired length and cutting with scissors.
Specifications
-
What’s Included: 1pc Dual OA Knee Brace / 1pc Allen Wrench / 1pc Phillips Head Screwdriver / 2pcs Extension Hinge-Stop Set (0-40 degrees) / 2pc Flexion Hinge-Stop Set (0-90 degrees).
-
Colors: Black.
-
Dimensions: 16.7 x 7.4 x 5.7 (W x H x L).
-
Weight: 1.61 pounds.
-
Materials: Aluminum, Polyester, Plastic, EVA.
- Latex-free.
Sizes
Size |
Circ. if Thigh in. |
Circ. of Calf in. |
S |
16.5” – 19.3” |
13.4” – 15” |
M |
19.3” – 22” |
15” – 16.5” |
L |
22” – 24.8” |
16.5” – 18” |
XL |
24.8” – 27.5” |
18” – 19.7” |
Product Files
FAQ
HCPCS Codes L1845 - L1852: Details and Uses
L1845: Knee orthosis, Double upright, thigh and calf, With adjustable flexion and extension joint (unicentric or polycentric), Medial-lateral and rotation control, With or without varus/valgus adjustment, Prefabricated item that has been trimmed, bent, molded, assembled, or otherwise customized to fit a specific patient by an individual with expertise.
L1852: Knee orthosis (KO), Double upright, thigh and calf, With adjustable flexion and extension joint (unicentric or polycentric), Medial-lateral and rotation control, With or without varus/valgus adjustment, Prefabricated, Off-the-shelf.
How can I Get the 845 Dual OA Knee Brace?
The 845 Dual OA Knee Brace is available to licensed medical professionals through the Vive Health Business Portal.
How to Adjust the Hinge on the 845 Dual OA Knee Brace:
- Use the Phillips head side of the included key to loosen the screws on the outer hinge cover.
- Place the hinge-stops provided to restrict range of motion to your desired extension or flexion (bend) on each side. Each hinge-stop is labeled with the degrees.
- Secure the screws back on and test.
How to Adjust the Unloading Mechanisms on the 845 Dual OA Knee Brace:
Use the Allen head side of the key provided and turn the unloading dial, located above the hinge, clock or counterclockwise to adjust the amount of pressure unloaded.
